INDUMATIK 150 Flexible manufacturing system.

individual

Number of pallets

individual

Number of pallets

400x400 / 320x320 mm

Pallet dimensions

400x400 / 320x320 mm

Palettenmaß

150 kg

Transfer weight

150 kg

Transfer weight

Compare

Configure

INDUMATIK 150

Designed as a flexible manufacturing system (FMS for short), the Indumatik 150 allows both the automation of a machining centre and the automation of a multi-machine system. The Indumatik 150 has a flexibly expandable pallet storage system and a rotating handling device that can be moved on a floor rail. The workpieces are clamped at a central storage/retrieval station during machining, which saves non-productive and distribution times at the machines. The automation of pallet transport also reduces space and labour costs and shortens order lead times. The individual orders and NC controls are coordinated via a central master computer.

Get the best out of your production

Greater productivity, higher delivery reliability, relieved employees: there are many good reasons for automation in production.

Less land consumption.

An automated machining centre often replaces several conventional machines. Productivity per area increases.

Increased productivity.

The majority of work steps can be automated. The selection of the right automation depends on the number of pieces, batch size, running time, dimensions and weight of the workpieces to be produced.

Improved quality.

Eine Automation liefert gleichbleibende Qualität, da sie nicht müde oder abgelenkt wird.

Lower operating costs.

Quality made in Germany and a fast, partnership-based service guarantee the high availability of our machines, reduce your downtimes and secure your economic advantage.

Reduced tooling times.

Whether pallet magazines, robot systems, large tool magazines or built-in zero-point clamping systems - HEDELIUS has the expertise to reduce your tooling times.

Maschinenvergleich.

Fügen Sie weitere Maschinen hinzu um Leistungsparameter zu vergleichen.


	INDUMATIK 150	Add machine	Add machine
	Storage/retrieval station
Storage/retrieval station	Yes	-	-
	Rotatable storage/retrieval station
Rotatable storage/retrieval station	No	-	-
	Pallet handling
Pallet handling	Yes	-	-
	Number of pallets
Number of pallets	individual	-	-
	Pallet dimensions
Pallet dimensions	400x400 / 320x320 mm	-	-
	Collision area diameter
Collision area diameter	-	-	-
	Transfer weight
Transfer weight	150 kg	-	-
	Manipulace s obrobky
Manipulace s obrobky	No	-	-
	Gripper
Gripper	Single	-	-
	Workpiece dimensions
Workpiece dimensions	-	-	-
	Workpiece storage
Workpiece storage	Shelving system	-	-
	Multi-machine operation
Multi-machine operation	Yes	-	-

Gallery of the INDUMATIK 150

Choose your compatible CNC machining centre.

What is usually considered special accessories is standard at HEDELIUS: All machining centres are equipped with a CNC full keyboard, colour monitor, spindle feed overdrive and original software as standard. State-of-the-art control technology from SIEMENS or HEIDENHAIN guarantees maximum operating convenience and unrestricted functionality. You decide which system you want to work with.

ACURA 50 EL

Travel paths (X/Y/Z)

Travel paths

500 x 550 x 550 mm

Dimensions rotating/swivelling table

Rotating table dimensions

Ø 500x430 mm

Load rotating/swivelling table max.

Turntable load

300 kg

ACURA 65 EL

Travel paths (X/Y/Z)

Travel paths

700 x 650 x 600 mm

Dimensions rotating/swivelling table

Rotating table dimensions

Ø 650x540 mm

Load rotating/swivelling table max.

Turntable load

500 kg

ACURA 85 EL

Travel paths (X/Y/Z)

Travel paths

900 x 850 x 700 mm

Dimensions rotating/swivelling table

Rotating table dimensions

Ø 850x750 mm

Load rotating/swivelling table max.

Turntable load

1000 kg

Additional equipment.

Expand your automation system.

Additional equipment.

Expand your automation system.

STANDBY magazine

HEDELIUS STANDBY Magazin für bis zu 70 / 115 zusätzliche Werkzeuge für HEDELIUS CNC Bearbeitungszentren

STANDBY Magazin 70 Capacity: 70

STANDBY Magazin 115 Capacity: 115

HEDELIUS STANDBY Magazin für bis zu 180 zusätzliche Werkzeuge für HEDELIUS CNC Bearbeitungszentren

STANDBY magazine 180 Capacity: 180

HEDELIUS STANDBY Magazin für bis zu 264 zusätzliche Werkzeuge für HEDELIUS CNC Bearbeitungszentren

STANDBY magazine 264 Capacity: 264

Chip press

Die Spänepresse schließt direkt am Späneförderer des HEDELIUS Bearbeitungszentrums an. Die bei der Bearbeitung anfallenden Späne werden gepresst und aus dem Reststoff wird so ein Wertstoff. So werden Platz und zusätzlich Entsorgungskosten gespart.

chip press

The chip press separates the chips from the cooling lubricants and compresses them into clean, manageable briquettes. For example, 300 litres of chips can be compressed into a few dozen briquettes. This corresponds to a volume reduction of approx. 80 %.

This is your new automation solution made in Germany.

INDUMATIK 150

Number of pallets

individual

Pallet dimensions

Palettenmaß

400x400 / 320x320 mm

Transfer weight

150 kg

Set-up options

STANDBY Magazin 70

STANDBY Magazin 115

STANDBY magazine 180

STANDBY magazine 264

chip press

Palettenautomation INDUNORM Indumatik Light 150

You are interested in a new automation system with a HEDELIUS machining centre. We will be happy to make you an offer, e.g. for a CNC machining centre, an automation solution, etc. from HEDELIUS Maschinenfabrik GmbH. We would be happy to demonstrate the output of our CNC machining centres in a practical demonstration or via video livestream.
